Elipson A2700 power amplifier

£2,999.00

Quantity:

Add To Cart

The A2700 power amplifier is the perfect complement to the P1 preamplifier. It can produce 400W RMS under 8 ohms in stereo mode or 1400 W RMS under 8 ohms in mono mode, capable of giving life and energy to any pair of floorstanding or bookshelf speakers. You have mono blocks of staggering capability when connected to a second A2700 in bridged mode.

"An iron fist in a velvet glove" is a good indicator of this amplifier's character. Like its partnering P1 preamplifier, the design was focused on the minimisation of background noise and distortion. You have a formidable performer when combining this attention to detail with rich dynamics and effortless musicality. It will highlight all the complexities of your music with finesse and has huge reserves of power to do so without breaking a sweat.

The A2700 power amplifier and the rest of the Elipson range are manufactured in France in their Burgundy factory.

TECHNICAL

Type: Compact speaker - 3 ways - Bass - reflex
Event : Flared - front face - Freq.d'accord: 37 Hz
Power : 130W RMS
Grave-medium : 210 mm cellulose pulp Medium: 55 mm treated dome
Tweeter : 22 mm silk dome
Crossover filter - Fc : 850 & 5000 Hz - 12dB/12dB-12dB/18dB
Frequency response (+/- 3dB) : 45-25,000 Hz
Fine control of medium & treble levels on the front panel: -1dB / 0dB (Ref) / +1dB
Recommended power: 50 - 150 W
Sensitivity: 90dB / 1W / 1m
Impedance: 6 Ohms (min 3 Ohms @2400 Hz)

DIMENSIONS
Dimensions: H x W x D: 560 x 320 x CHARACTERISTICS

TECHNICAL DATA

RMS power Wrms / channel / 8 Ω Class D : 400 W @ THD=1 % (clipping) 2 channels on
Harmonic Distortion (THD) at 100 W @ 8 Ω : < 0,005 % @ 1kHz
Harmonic Distortion (THD) at 1 W @ 8 Ω : < 0.003 % @ 1kHz
Intermodulation Distortion (IMD SMPTE) at 100 W : < 0.01%.
RMS power Wrms / channel / 4 Ω : 710 W @ THD=1 % (2 x 750 W peak with CF*=12 dB)
RMS power Wrms clamped mode 8Ω : 1400 W / 2500 W peak with CF=12 dB
Impulse power : 2 x 900 W under 2 Ohms with CF=12 dB
Power consumption (230 Vac / 120 Vac) : 250 W with PF* = 0,96 at Pmax/8 at 4 Ω 2 channels
Number of inputs : 1 x RCA Stereo + 1 x XLR Stereo + trigger In and Out
Input impedance : 1 MΩ
Sensitivity (V) : 9,5 dBu (sym), 3,5 dBu (asym) (2,3 V /1,15 V)
Rise time (μs) : 5ms at Pmax 8 Ω
Bandwidth : 2 Hz - 60 kHz @ -3 dB at 4 Ω
Damping Factor : 1000 at 8 Ohms between 20 Hz and 2 kHz
Signal to Noise Ratio (Dynamic) : 119 dB (balanced input) at Pmax in stereo
Max Operating Temperature : 40° C
Output configurations : Stereo / Mono bridge

Clipping LED and protection LED (current, power, temperature) per channel. Trigger input and output for stand-by and operation by isolated voltage (5 to 12 V). * CF = peak factor (10 log (P peak/P average)) ** PF = power factor (cos phi)
