System
3,0 way
Midrange sealed cork enclosure
Woofers down vented box
Loudspeakers
High-end quality drivers
Tweeter: 1,1" DAD™ Arrow Point extended frequency tweeter, Copper shorting ring
Midrange: 1x 6,5" Camelia midrange, Copper shorting ring
Woofer: 2 x 8" woofers, Aluminum demodulation ring
Crossover Points
350 Hz - 2500 Hz
Frequency response
33 Hz - 40.000 Hz
Sensitivity
90 dB SPL (2.83 V/1m)
Nominal impedance
4 Ohm
Recommended power amplifier
50 W - 400 W
Product dimensions (HxWxD)
1190 - 334 - 480 mm / each
46.8 - 13.15 - 18.9 in /each
Dimensions with packaging (HxWxD)
1290 - 445 - 585 mm / each
50.79 - 17.52 - 23.03 in / each
Weight
45 kg / each
99.21 lb /each
Packaging weight
100,4 kg / two cartons with one speaker each
221.3 lb / two cartons with one speaker each
Cabinet
Lute shape
Wood
Leather
Concrete
