System

2-way shelf loudspeaker system.
Vented box design

Loudspeakers
Tw: Ø 29 mm high definition DAD™ driver, Visco-elastically baffle decoupling, Ferrite, Soft Dome.
Mw: Ø 150 mm cone driver

Crossover Points
Crossover point: 1800 Hz.
Optimized amplitude/phase response for optimal space/time performance, Hi-Fi

Frequency response
55 Hz - 24000 Hz

Sensitivity
86 db SPL (2.83V/1 m)

Nominal impedance
4 Ohm

Recommended power amplifier
30W - 150W, undistorted signal

Connectivity
4 connectors binding post: Hi, Mid-Low

Decoupling Systems
Rubber pad

Product dimensions (HxWxD)
304 x 180 x 263 mm / each
12 x 7.1 x 10.3 in / each

Dimensions with packaging (HxWxD)
435 x 380 x 490 mm / pair
17.1 x 15 x 19.3 in / pair

Weight
5,8 Kg / each
12.8 lb / each

Packaging weight
14 Kg / pair
30.9 lb / pair

Cabinet
Squared
