Transrotor MM Uccello Reference cartridge
The Transrotor Uccello Reference mm is based on the Goldring G1000 series. The special diamond cut and extreme selection result in a particularly spatial and three-dimensional sound without any high-frequency emphasis.
The patented diamond cut compensates for irregularities and even old and dirty records are reproduced with a low level of noise and crackling. It is particularly suitable for Rega, Dual, Thorens, Transrotor, OriginLive and other tone arms.
This model is very similar to the Transrotor Cantare MC tonearm. If you're not sure which one to choose, only the quality of a high end MC phono preamplifier can tell the difference. This makes the uccello reference an ideal choice for a mm cell
The Transrotor Uccello Reference mm is based on the Goldring G1000 series. The special diamond cut and extreme selection result in a particularly spatial and three-dimensional sound without any high-frequency emphasis.
The patented diamond cut compensates for irregularities and even old and dirty records are reproduced with a low level of noise and crackling. It is particularly suitable for Rega, Dual, Thorens, Transrotor, OriginLive and other tone arms.
This model is very similar to the Transrotor Cantare MC tonearm. If you're not sure which one to choose, only the quality of a high end MC phono preamplifier can tell the difference. This makes the uccello reference an ideal choice for a mm cell
Transducer :
Frequency response: 20 Hz - 25 kHz ± 2 dB
Channel balance: 1 dB max. at 1 kHz
Channel separation: 27 dB min. at 1 kHz
Output voltage: 6.5 mV ± 1 dB at 1 kHz
Diamond flexibility: 24 mm/N
Diamond weight: 0.20 mg
Reading angle: 24º.
Diamond grinding : Harmonic
Diamond type: Interchangeable
Electrical characteristics:
Termination resistance: 47 kΩ
Load capacity: 150 - 200 pF
Self-inductance: 570 μH
Intrinsic resistance: 660 Ω
Mechanical characteristics:
Bearing force: 1.5 - 2.5 g (Nominal: 1.75 g)
Mounting holes: 12.7 mm (0.5 in)
Cell weight: 6.3 g
